DeviceNet Board for FANUC Series 30i/300i, 31i/310i, 32i/320i-MODEL A Operators manual Page 34

Operators manual
1.DeviceNet FUNCTIONS SETTING B-64044EN/01
- 26 -
Display item
Item Description
NODE STATUS
LIST
The statuses of nodes are listed.
* : Local node
○ : Node during I/O communication
E : Node on which an I/O communication error
occurs
- : Node not added to the network
NODE NO. The node number (MAC ID) is displayed.
The display range is between 0 and 63.
STATUS The node status is displayed.
－－－ : Local node
COM OK : Node during I/O communication
COM ERROR : Node on which an I/O communication
error occurs
DISABLE : Node not added to the network
RETRY COUNT The cumulative number of retries of I/O
communication made during occurrence of an I/O
communication error is displayed. Counting up stops
when the retry count reaches 255.
For the local node (master), "---" is displayed.
The display range is between 0 and 255.
VENDOR ID The vendor ID is displayed.
The display range is between 0000H and FFFFH.
Example) 024FH:FANUC LTD
DEVICE TYPE The device type is displayed.
The display range is between 0000H and FFFFH.
Example) 000CH:Communication adaptor
PRODUCT CODE The product code is displayed.
The display range is between 0000H and FFFFH.
Example) 0002H:A20B-8101-0220
SELECT NODE
When you press soft key [SELECT NODE] after entering the node
number (MAC ID) of a slave with the MDI key, the detailed
information (status, retry count, vendor ID, device type, and product
code) on the corresponding node number is displayed.
