Series 0i-PB Parameter manual Page 106

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63980EN/01
98
3622
Number of the pitch error compensation position at extremely positive position
for each axis
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Word axis
[Unit of data] Number
[Valid data range] 0 to 1023
Set the number of the pitch error compensation position at the extremely
positive position for each axis.
This value must be larger than set value of parameter (No.3620).
3623 Magnification for pitch error compensation for each axis
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Byte axis
[Unit of data] 1
[Valid data range] 0 to 100
Set the magnification for pitch error compensation for each axis.
If the magnification is set to 1, the same unit as the detection unit is used
for the compensation data. If 0 is set, the same magnification selected by
setting 1 is selected.
3624 Interval between pitch error compensation positions for each axis
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] 2–word axis
[Unit of data]
Increment system IS–A IS–B Unit
Millimeter machine 0.01 0.001 mm
Inch machine 0.001 0.0001 inch
Rotation axis 0.01 0.001 deg
[Valid data range] 0 to 99999999
The pitch error compensation positions are arranged with equal spacing.
The space between two adjacent positions is set for each axis. The
minimum interval between pitch error compensation positions is limited
and obtained from the following equation:
