FS 16i/18i-TA/TB (2 or 3 paths) Improvement of Rigid tapping with spindle of another path (Spindle select by address P) Specifications Supplement to Manual Page 1

Supplement to Manual
FANUC Series 16i / 18i – TA / TB
(2 or 3 paths)
Improvement of Rigid tapping with spindle of another path
(
Spindle select by address P)
Specifications
Ed.
Page
Name
No.
Date
Contents
Draw u
p
FS16
i
/18
i
-TA/TB (2 or 3 path)
Improvement of Rigid tapping with spindle of another path
(Spindle select by address P) Specifications
A-79156E
2003.06.01
1/11
T. K
(2)
p
art chan
g
ed.
02
030703
Apprv.
Desig.
Desi
g
n
T. Kurokawa E. Genma
Previous page
Next page

Contents Summary of FS 16i/18i-TA/TB (2 or 3 paths) Improvement of Rigid tapping with spindle of another path (Spindle select by address P) Specifications Supplement to Manual

  • Page 1FANUC Series 16i / 18i – TA / TB (2 or 3 paths) Improvement of Rigid tapping with spindle of another path (Spindle select by address P) Specifications Name FS16i/18i-TA/TB (2 or 3 path) Improvement of Rigid tapping with spindle of another path (Spindle select by address P) Specifications No. A-79156
  • Page 21. OVERVIEW By the setting of parameters SPR (No.3703#4)=1, MPP (No.3703#3)=1, the following is available. When you perform rigid tapping with 2-path lathe (2-CPU 2-path or 1-CPU 2-path lathe) or 3-path lathe, you can perform rigid tapping using the spindle connected to a path other than that with w
  • Page 32. SPECIFICATIONS 2.1 USAGE By the setting of parameters SPR (No.3703#4)=1, MPP (No.3703#3)=1, the following is available. When you perform rigid tapping with 2-path lathe (2-CPU 2-path or 1-CPU 2-path lathe) or 3-path lathe, you can perform rigid tapping using the spindle connected to a path other
  • Page 42.2 EXAMPLE OF USE [Example] System: 2-spindle and 2-path control (parameter 2SP (No.3703 #0) = 1) with a 2-path lathe Command: The rigid tapping of the following combination. • Command (Work program) from path1 • Servo (Z #1 of the figure below) which is connected to path 1. • Spindle (SP2 #2 of th
  • Page 52.3 RESTRICTIONS Please note the following restrictions: (1) The path with which to specify rigid tapping and the spindle with which to perform rigid tapping must have a one-to-one correspondence. (2) Before using this function to perform rigid tapping using the spindle of another path, you must set
  • Page 6(Supplement) In the rigid tapping by other path spindle, in case of parameter MPP (No.3703#3)=1 (the specification which is shown in this book), it is possible to control even if "The path to command" and "The path which is exist the spindle" are not one-to-one correspondence. Therefore, " The combi
  • Page 73. PARAMETER #7 #6 #5 #4 #3 #2 #1 #0 3703 SPR MPP [Data type] Bit type, common to all paths When these parameters are modified, POWER MUST BE OFF alarm occurs. SPR On 2- or 3-path lathe, the rigid tapping with spindle of another path function is: 0: Not available 1: Available MPP In multi-spindle co
  • Page 8(NOTE) If you use this function to perform rigid tapping with the spindle connected to another path, the parameters listed below will follow the settings of the path to which the spindle is connected: No.3706#0,#1，No.3707#0,#1，No.3707#2, #3 No.5200#1，No.5200#4，No.5201#2，No.5201#3，No.5204#1 No.5211 (
  • Page 94. ALARM No. Message Description 5354 P/S ALARM (1) The spindle which was selected with the P code which was commanded with rigid M code (Exp. M29) was executing rigid tapping already or tried to execute. (2) The spindle which was selected with the P code which was commanded with rigid M code (Ex. M
  • Page 105. CAUTIONS This function is effective when using a serial spindle and multi- spindle control option at the 2 path lathe (2-CPU 2 path or 1-CPU 2 path) or the 3 system lathe. When executing rigid tapping with the spindle of the another path, the ENB signal moves to the spindle side of the path accor
  • Page 116. References The main, related explanatory documents are listed below: - "Rigid tapping with spindle of another path Specifications" (A-78374E) - "Spindle select by address P (Multi-spindle control) Specifications" (A-77777E) - "Additional function of spindle select by address P (Multi-spindle cont
