4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 98 -
# 5 ANA When an abnormal load is detected for an axis:
0: Movement along all axes is stopped, and a servo alarm is output.
1: No servo alarm is output, and movement along only the axes of
the group containing the axis with the abnormal load is stopped
in interlock mode. (The group number of each axis is set in
parameter No.1881.)
# 6 SAK When the VRDY OFF alarm ignore signal IGNVRY is 1, or when the
VRDY OFF alarm ignore signals IGNVRYn are 1:
0: Servo ready signal SA is set to 0.
1: Servo ready signal SA remains set to 1.
#7 #6 #5 #4 #3 #2 #1 #0
1805 TSM TSA TRE
[Input type] Parameter input
[Data type] Bit path
# 1 TRE When bit 4 of parameter No. 1803 is set to 0 (not to perform
follow-up operation with a torque control command in PMC axis
control), the servo error counter is:
0: Updated.
When the error count exceeds the maximum allowable
cumulative travel value (parameter No. 1885), the alarm
(SV0423) is issued.
1: Not updated.
No errors are accumulated, so that the alarm (SV0423) is not
issued. When the maximum allowable feedrate is exceeded,
however, the alarm (SV0422) is issued.
To return to position control when this parameter bit is set to 1, a
reference position return operation needs to be performed.
# 3 TSA As the abnormal load detection level during dwell, M code execution,
and automatic operation halt state:
0: The threshold value for rapid traverse is used. (parameter
No.2142)
1: The threshold value for cutting feed is used. (parameter No.2104)
This parameter is valid when bit 3 (ABG0) of parameter No. 2200 is
set to 1.
# 4 TSM As the abnormal load detection level in the jog feed mode (excluding
manual rapid traverse) and manual handle feed mode:
0: The threshold value for rapid traverse is used. (parameter
No.2142)
1: The threshold value for cutting feed is used. (parameter No.2104)
This parameter is valid when bit 3 (ABG0) of parameter No. 2200 is
set to 1.
#7 #6 #5 #4 #3 #2 #1 #0
1814 ALGx
