4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 100 -
position on the absolute position detector, and sets this parameter to 1
automatically.
# 5 APCx Position detector
0: Other than absolute position detector
1: Absolute position detector (absolute pulse coder)
# 6 RONx With a rotation axis, a rotary encoder for detecting an absolute
position within one revolution is:
0: Not used.
1: Used.
#7 #6 #5 #4 #3 #2 #1 #0
1816 DM3x DM2x DM1x
[Input type] Parameter input
[Data type] Bit axis
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
#4 DM1
#5 DM2
#6 DM3
By using DM1, DM2, and DM3, a detection multiplication factor
(DMR) is set.
This parameter is valid when a separate position detector (AB phase)
is used and parameter No. 2084 and No. 2085 are not set.
DM3 DM2 DM1 DMR
0 0 0 1/2
0 0 1 1
0 1 0 3/2
0 1 1 2
1 0 0 5/2
1 0 1 3
1 1 0 7/2
1 1 1 4
#7 #6 #5 #4 #3 #2 #1 #0
1817 TANx SCPx SBLx
[Input type] Parameter input
[Data type] Bit axis
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 2 SBLx Smooth backlash compensation is :
0: Disabled.
1: Enabled.
