4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 138 -
# 6 DAK When absolute coordinates are displayed in the three-dimensional
coordinate conversion mode:
0: Coordinates in the program coordinate system are displayed.
1: Coordinates in the workpiece coordinate system are displayed.
#7 #6 #5 #4 #3 #2 #1 #0
3108 JSP SLM WCI PCT
[Input type] Parameter input
[Data type] Bit path
# 2 PCT For modal T display on the program check screen:
0: A specified T value is displayed.
1: HD.T and NX.T are displayed.
Values displayed follow bit 1 of parameter No. 13200.
# 4 WCI On the workpiece coordinate system screen, a counter input is:
0: Disabled.
1: Enabled.
# 6 SLM The spindle load meter is:
0: Not displayed.
1: Displayed.
NOTE
This parameter is valid only when bit 2 (DPS) of
parameter No. 3105 is set to 1.
# 7 JSP On the current position display screen and program check screen, jog
feed is:
0: Not displayed.
1: Displayed.
In manual operation mode, the jog feedrate is displayed. In
automatic operation mode, the dry run feedrate is displayed. In each
case, the feedrate to which a manual feedrate override has been
applied is displayed.
#7 #6 #5 #4 #3 #2 #1 #0
3109 IKY DWT
[Input type] Parameter input
[Data type] Bit path
# 1 DWT Characters G and W in the display of tool wear/geometry
compensation amount
0: The characters are displayed at the left of each number.
1: The characters are not displayed.
# 2 IKY On the tool offset screen and workpiece shift screen (T series), soft
key [INPUT] is:
0: Displayed.
