B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 139 -
1: Not displayed.
#7 #6 #5 #4 #3 #2 #1 #0
3111 SVP SPS SVS
[Input type] Setting input
[Data type] Bit path
# 0 SVS Servo setting screen and servo tuning screen
0: Not displayed
1: Displayed
# 1 SPS Spindle tuning screen
0: Not displayed
1: Displayed
# 2 SVP Spindle synchronization errors displayed on the spindle tuning screen
0: Instantaneous values are displayed.
1: Peak-hold values are displayed.
Spindle synchronization errors are displayed on the side of the spindle
that functions as a slave axis in spindle synchronization control.
#7 #6 #5 #4 #3 #2 #1 #0
3112 OMH
[Input type] Parameter input
[Data type] Common to the bit system
# 2 OMH The external operator message history screen is:
0: Not displayed.
1: Displayed.
#7 #6 #5 #4 #3 #2 #1 #0
3113 DCL ALP
[Input type] Parameter input
[Data type] Bit
# 1 ALP Alphabetic character input using soft keys is:
0: Disabled.
1: Enabled.
NOTE
This parameter is valid only with a 10.4-inch
display unit.
# 5 DCL The touch panel compensation screen is:
0: Disabled.
1: Enabled.
Set this parameter to 0 usually. Touch panel compensation becomes
necessary only when the panel is replaced or memory all clear
