4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 154 -
#7 #6 #5 #4 #3 #2 #1 #0
3280 NLC
[Input type] Parameter input
[Data type] Bit
# 0 NLC Dynamic display language switching is:
0: Enabled.
1: Disabled.
When dynamic display language switching is disabled, the language
setting screen is not displayed. In this case, change the setting of
parameter No. 3281 on the parameter screen then turn on the power
again to switch the display language.
3281 Display language
[Input type] Parameter input
[Data type] Byte
[Valid data range] 0 to 14
Select a display language from the following:
0 : English
1 : Japanese
2 : German
3 : French
4 : Chinese
5 : Italian
6 : Korean
7 : Spanish
8 : Dutch
9 : Danish
10 : Portuguese
11 : Polish
12 : Hungarian
13 : Swedish
14 : Czech
If a number not indicated above is set, English is selected.
#7 #6 #5 #4 #3 #2 #1 #0
KEY GO2 IWZ WZO GOF WOF
3290
KEY IWZ WZO GOF WOF
[Input type] Parameter input
[Data type] Bit path
# 0 WOF Setting the tool offset value (tool wear offset) by MDI key input is:
0: Not disabled
1: Disabled (With parameter No.3294 and No.3295, set the offset
number range in which updating the setting is to be disabled.)
