B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 203 -
NOTE
4 Identical P code values cannot be used for
different spindles. (Identical P code values cannot
be used even if the paths are different.)
5 When this parameter is used (when bit 3 (MPP) of
parameter No. 3703 is set to 1), the spindle
command selection signal is invalid.
6 To use this parameter, the multi-spindle control
function is needed.
#7 #6 #5 #4 #3 #2 #1 #0
3798 ESN ALM
[Input type] Parameter input
[Data type] Bit
# 0 ALM The spindle alarm (SP****) for all spindles is:
0: Enabled.
1: Ignored.
When this parameter is set to 1, the spindle-related alarms are ignored.
So, be sure to set this parameter to 0 at all times except for special
cases such as maintenance.
# 1 ESN When the multi-spindle function is enabled and bit 3 (MPP) of
parameter No. 3703 is set to 1, a spindle is specified in a program by
using:
0: P command.
1: Extended spindle name.
A spindle to be specified is selected as follows:
ESN
(No.3798#1)
MPP
(No.3703#3)
Selection method
0 0 Signal selection
0 1 P command
1 0 Signal selection
1 1 Extended spindle name
NOTE
This parameter is valid when bit 0 (EEA) of
parameter No. 1000 is set to 1.
When setting this parameter to 1, set also
parameter No. 3738 and No. 3739 properly.
