4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 220 -
#7 #6 #5 #4 #3 #2 #1 #0
4959 DMDx
[Input type] Parameter input
[Data type] Bit axis
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 0 DMDx A machine coordinate on the spindle positioning axis is displayed in:
0: Degrees.
1: Pulses.
4960 M code specifying the spindle orientation
[Input type] Parameter input
[Data type] 2-word spindle
[Valid data range] 6 to 97
Set an M code for switching to the spindle positioning mode.
NOTE
1 Do not set an M code that duplicates other M
codes used for spindle positioning.
2 Do not set an M code used with other functions
(such as M00-05, 30, 98, and 99, and M codes for
calling subprograms).
4961 M code releasing the spindle positioning mode
[Input type] Parameter input
[Data type] 2-word spindle
[Valid data range] 6 to 97
Set an M code for canceling the spindle positioning mode on the
spindle positioning axis.
NOTE
1 Do not set an M code that duplicates other M
codes used for spindle positioning.
2 Do not set an M code used with other functions
(such as M00-05, 30, 98, and 99, and M codes for
calling subprograms).
