B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 233 -
1: Used.
5010
Limit for ignoring the small movement resulting from cutter compensation or
tool nose radius
[Input type] Setting input
[Data type] Real path
[Unit of data] mm, inch (input unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 to +999999.999)
When the tool moves around a corner in cutter compensation or tool
nose radius compensation mode, the limit for ignoring the small travel
amount resulting from compensation is set. This limit eliminates the
interruption of buffering caused by the small travel amount generated
at the corner and any change in feedrate due to the interruption.
Even if
∆
V
x
≤
∆
V
limit
and
∆
V
Y
≤
∆
V
limit
, vector to
single-block stop point
remains.
Tool center path
Pro
g
rammed
p
ath
If ∆V
x
≤ ∆V
limit
and ∆V
Y
≤ ∆V
limit
,
this vector is ignored.
S
∆
V
Y
∆
V
x
r
r
N1
N2
∆
V
limit
is determined depending on the setting in parameter No. 5010.
