4.DESCRIPTION OF PARAMETERS B-63950EN/02

- 234 -

5011

Constant denominator for three-dimensional tool compensation or tool

length compensation in a specified direction

[Input type] Setting input

[Data type] Real path

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 to +999999.999)

This parameter sets the value of p in the expressions used for finding a

three-dimensional tool compensation vector:

priVx /

prjVy /

prkVz /

where,

VyVx ,, : Components of a three-dimensional tool compensation

vector along the X-axis, Y-axis, and Z-axis, or their

parallel axes

kji ,, : Values specified in addresses I, J, and K in the program

: Compensation value

p : Value set in this parameter

When 0 is set in this parameter, the following is assumed:

222

KJIp ++=
