4.DESCRIPTION OF PARAMETERS B-63950EN/02

- 240 -

5024 Number of tool compensation values

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Input type] Parameter input

[Data type] Word path

[Valid data range] 0 to 999

Set the maximum allowable number of tool compensation values used

for each path.

Ensure that the total number of values set in parameter No. 5024 for

the individual paths is within the number of compensation values

usable in the entire system. The number of compensation values

usable in the entire system depends on the option configuration.

If the total number of values set in parameter No. 5024 for the

individual paths exceeds the number of compensation values usable in

the entire system, or 0 is set in parameter No. 5024 for all paths, the

number of compensation values usable for each path is a value

obtained by dividing the number of compensation values usable in the

entire system by the number of paths.

Tool compensation values as many as the number of compensation

values used for each path are displayed on the screen. If tool

compensation numbers more than the number of compensation values

usable for each path are specified, an alarm is issued.

For example, 64 tool compensation sets are used, 20 sets may be

allocated to path 1, 30 sets to path 2, and 14 sets to path 3. All of 64

sets need not be used.

Number of digits of an offset number used with a T code command

5028

[Input type] Parameter input

[Data type] Byte path

[Valid data range] 0 to 3

Specify the number of digits of a T code portion that is used for a tool

offset number (wear offset number when the tool geometry/wear

compensation function is used).

When 0 is set, the number of digits is determined by the number of

tool compensation values.

When the number of tool compensation values is 1 to 9: Lower 1 digit

When the number of tool compensation values is 10 to 99: Lower 2

digits

When the number of tool compensation values is 100 to 999: Lower 3

digits

Example :

When an offset number is specified using the lower 2 digits of a

T code, set 2 in parameter No. 5028.

Txxxxxx yy

xxxxxx : Tool selection
