4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 244 -
NOTE
Do not change the setting of this parameter in the
active offset value modification mode.
# 6 AON If a change is made to a tool compensation value (tool length
compensation value used with tool length compensation A/B in the
case of the M series):
0: In the case of the M series, the change becomes effective starting
with the next block specifying G43, G44, or an H code.
In the case of the T series, the change becomes effective starting
with the next block specifying a T code.
1: The change becomes effective starting with the next block to be
buffered.
NOTE
1 This parameter is valid when bit 6 (EVO) of
parameter No. 5001 is set to 0.
2 The operation of this parameter set to 1 is valid
even if a new compensation value is further
changed by MDI input or a G10 command before
the new compensation value becomes effective.
3 The operation of this parameter set to 1 is invalid if
a reset operation is performed before a new
compensation value becomes effective.
