3.INPUTTING AND OUTPUTTING PARAMETERS THROUGH THE READER/PUNCHER INTERFACE B-63950EN/02
- 14 -
3.3.10 Byte/Word/Two-Word Path Format
N ***** Q1 L ** P ****** L **
P
******
･ ･ ･
;
A numeric value after N represents a parameter number.
Q1 indicates that the data is parameter data.
A numeric value after L represents a path number (1 and up).
A numeric value after P represents the value (integer) of a parameter
for each path.
A semicolon (;) marks the end of a block. (LF is used for the ISO
code, and CR is used for the EIA code.)
Example
N01020Q1L1P88L2P89L3P90......;
Parameter No. 1020
Parameter value Path 1: 88
Path 2: 89
Path 3: 90
▪
3.3.11 Byte/Word/Two-Word Axis Format
N ***** Q1 A ** P ****** A **
P
******
･ ･ ･
;
A numeric value after N represents a parameter number.
Q1 indicates that the data is parameter data.
A numeric value after A represents a controlled axis number (1 and
up).
A numeric value after P represents the value (integer) of a parameter
for each controlled axis.
A semicolon (;) marks the end of a block. (LF is used for the ISO
code, and CR is used for the EIA code.)
Example
N01020Q1A1P88A2P89A3P90A4P66......;
Parameter No. 1020
Parameter value 1st axis: 88
2nd axis: 89
3rd axis: 90
4th axis: 66
▪
