4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 266 -
4.22 PARAMETERS OF RIGID TAPPING
#7 #6 #5 #4 #3 #2 #1 #0
SRS FHD PCP DOV SIG CRG G84
5200
FHD PCP DOV SIG CRG G84
[Input type] Parameter input
[Data type] Bit path
# 0 G84 Method for specifying rigid tapping
0: An M code specifying the rigid tapping mode is specified prior to
the issue of the G84 (or G74) command. (See parameter
No.5210).
1: An M code specifying the rigid tapping mode is not used. (G84
cannot be used as a G code for the tapping cycle; G74 cannot be
used for the reverse tapping cycle.)
# 2 CRG Rigid mode when a rigid mode cancel command is specified (G80,
G01 group G code, reset, etc.)
0: Canceled after rigid tapping signal RGTAP is set to "0".
1: Canceled before rigid tapping signal RGTAP is set to "0".
# 3 SIG When gears are changed for rigid tapping, the use of SINDs is
0: Not permitted.
1: Permitted.
# 4 DOV Override during extraction in rigid tapping
0: Invalidated
1: Validated (The override value is set in parameter No.5211.
However, set an override value for rigid tapping return in
parameter No. 5381.)
# 5 PCP Rigid tapping
0: Used as a high-speed peck tapping cycle
1: Not used as a high-speed peck tapping cycle
# 6 FHD Feed hold and single block in rigid tapping
0: Invalidated
1: Validated
# 7 SRS To select a spindle used for rigid tapping in multi-spindle control:
0: The spindle selection signals SWS1, SWS2, SWS3, and SWS4
are used. (These signals are used also for multi-spindle control.)
1: The rigid tapping spindle selection signals RGTSP1, RGTSP2,
RGTSP3, and RGTSP4 are used. (These signals are provided
expressly for rigid tapping.)
