B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 275 -
5300 Tapping axis in-position width in rigid tapping (first spindle)
[Input type] Parameter input
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter sets a tapping axis in-position width when rigid
tapping is performed using the first spindle.
NOTE
Set the following parameter for each spindle:
First spindle No.5300
Second spindle No.5302
Third spindle No.5304
Fourth spindle No.5306
5301 Spindle in-position width in rigid tapping
[Input type] Parameter input
[Data type] Word spindle
[Unit of data] Detection unit
[Valid data range] 0 to 32767
These parameters are used to set spindle in-position widths in rigid
tapping.
NOTE
If an excessively large value is specified, the
threading precision will deteriorate.
5302 Tapping axis in-position width in rigid tapping (second spindle)
[Input type] Parameter input
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter sets a tapping axis in-position width when rigid
tapping is performed using the second spindle.
5304 Tapping axis in-position width in rigid tapping (third spindle)
[Input type] Parameter input
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter sets a tapping axis in-position width when rigid
tapping is performed using the third spindle.
