B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 303 -
# 3 TSE Custom macro interrupt signal UINT
0: Edge trigger method (Rising edge)
1: Status trigger method
# 4 MPR Custom macro interrupt valid/invalid M code
0: M96/M97
1: M code set using parameters (Nos. 6033 and 6034)
# 5 MSB Interrupt program
0: Uses a dedicated local variable (Macro-type interrupt)
1: Uses the same local variable as in the main program
(Subprogram- type interrupt)
# 7 MUS Interrupt-type custom macro
0: Not used
1: Used
#7 #6 #5 #4 #3 #2 #1 #0
VHD NAT
6004
D15 NAT
[Input type] Parameter input
[Data type] Bit path
# 0 NAT The results of the custom macro functions ATAN (with 2 arguments)
and ASIN are specified as follows:
0: The result of ATAN is 0 to 360.0.
The result of ASIN is 270.0 to 0 to 90.0.
1: The result of ATAN is -180.0 to 0 to 180.0.
The result of ASIN is -90.0 to 0 to 90.0.
# 2 VHD With system variables #5121 to #5140:
0: The tool offset value (geometry offset value) in the block
currently being executed is read. (This parameter is valid only
when tool geometry/tool wear compensation memories are
available.)
1: An interrupt travel distance based on manual handle interrupt is
read.
