4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 316 -
NOTE
1 If the same M code is set in these parameters, the
younger number is called preferentially. For
example, if 200 is set in parameter No. 6081 and
No. 6082, and programs O9021 and O9022 both
exist, O9021 is called when M200 is specified.
2 If the same M code is set in a parameter (No. 6071
to No. 6079) used to call subprograms and in a
parameter (No. 6080 to No. 6089) used to call
custom macros, a custom macro is called
preferentially. For example, if 300 is set in
parameter No. 6071 and No. 6081, and programs
O9001 and O9021 both exist, O9021 is called
when M300 is specified.
6090 ASCII code that calls the subprogram of program number 9004
6091 ASCII code that calls the subprogram of program number 9005
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 65(A:41H) to 90(Z:5AH)
These parameters set the ASCII codes that call subprograms in
decimal.
The settable addresses are indicated below.
Address Parameter setting value T series M series
A 65 O O
B 66 O O
D 68 X O
F 70 O O
H 72 O O
I 73 O O
J 74 O O
K 75 O O
L 76 O O
M 77 O O
P 80 O O
Q 81 O O
R 82 O O
S 83 O O
T 84 O O
V 86 X O
X 88 X O
Y 89 X O
Z 90 X O
NOTE
1 When address L is set, the number of repeats
cannot be specified.
2 Set 0 when no subprogram is called.
