B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 319 -
# 7 SKPXE For the skip function (G31), the skip signal SKIP is:
0: Disabled.
1: Enabled.
Whether the skip signals are enabled or disabled
Parameter
IGX
(No.6201#4)
GSK
(No.6200#0)
SKPXE
(No.6201#7)
Skip signal
SKIPP
Skip signal
SKIP
Multistage skip
signals
SKIP2-SKIP8
0 0 0 Disabled Enabled Enabled
0 1 0 Enabled Enabled Enabled
0 0 1 Disabled Disabled Enabled
0 1 1 Enabled Disabled Enabled
1 0 0 Disabled Disabled Disabled
1 1 0 Disabled Disabled Disabled
1 0 1 Disabled Disabled Disabled
Setting
1 1 1 Disabled Disabled Disabled
Bit 4 (IGX) of parameter No. 6201 is valid for the skip function using
high-speed skip signals (when bit 4 (HSS) of parameter No. 6200 is
set to 1) or for the multistage skip function using high-speed skip
signals (when bit 5 (SLS) of parameter No. 6200 is set to 1).
To use multistage skip signals, the multistage skip function option is
required.
#7 #6 #5 #4 #3 #2 #1 #0
6202 1S8 1S7 1S6 1S5 1S4 1S3 1S2 1S1
[Input type] Parameter input
[Data type] Bit path
1S1 to 1S8 These parameters specify whether to enable or disable each
high-speed skip signal when the G31 skip command is issued.
The following table shows the correspondence between the bits, input
signals, and commands.
The settings of the bits have the following meaning :
0: The high-speed skip signal corresponding to a bit is disabled.
1: The high-speed skip signal corresponding to a bit is enabled.
Parameter High-speed skip signals
1S1 HDI0
1S2 HDI1
1S3 HDI2
1S4 HDI3
1S5 HDI4
1S6 HDI5
1S7 HDI6
1S8 HDI7
NOTE
Do not specify the same signal simultaneously for
different paths.
