B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 353 -
4.45 PARAMETERS OF PROGRAM RESTART
#7 #6 #5 #4 #3 #2 #1 #0
7300 MOU MOA
[Input type] Parameter input
[Data type] Bit path
# 6 MOA In program restart operation, before movement to a machining restart
point:
0: The last M, S, T, and B codes are output.
1: All M codes and the last S, T, and B codes are output.
This parameter is enabled when the MOU parameter is set to 1.
# 7 MOU In program restart operation, before movement to a machining restart
point after restart block search:
0: The M, S, T, and B codes are not output.
1: The last M, S, T, and B codes are output.
#7 #6 #5 #4 #3 #2 #1 #0
7301 ROF
[Input type] Parameter input
[Data type] Bit path
# 0 ROF When the coordinates for restarting are displayed on the program
restart screen:
0: Tool length compensation (M series), tool position compensation
(T series), cutter compensation (M series), and tool-nose radius
compensation (T series) are considered.
1: Whether these compensation values are considered depends on
the settings of bits 7 and 6 of parameter No. 3104 and bit 1 of
parameter No. 3129 (parameters for specifying whether to
consider each compensation value).
7310
Ordinal number of an axis along which a movement is made in dry run after
program restart
[Input type] Setting input
[Data type] Byte axis
[Valid data range] 1 to (Number of controlled axes)
This parameter sets the ordinal number of an axis along which a
movement is made in dry run after the program is restarted.
