B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 381 -
8020 FL feedrate for reference position return along each axis in PMC axis control
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
For each axis, this parameter sets a feedrate (FL feedrate) after
deceleration for reference position return in PMC axis control.
NOTE
If 0 is specified, the value of parameter No. 1425 is
used.
8022 Upper limit rate of feed per revolution during PMC axis control
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
This parameter sets the upper limit rate of feed per revolution during
PMC axis control.
8028
Time for acceleration/deceleration calculation when a feedrate is specified
under PMC axis control
[Input type] Parameter input
[Data type] Word axis
[Unit of data] msec
[Valid data range] 0 to 32767
When a feedrate is specified under PMC axis control,
acceleration/deceleration can be set for parameter No. 8032 or this
parameter. When 0 is set in parameter No. 8032, the specification of
1000 min
-1
is assumed. When 0 is set in this parameter, the
acceleration/deceleration function for feedrate specification is
disabled.
