B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 403 -
8181 Synchronization error limit of each axis
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] Detection unit
[Valid data range] 0 to 99999999
When the synchronization deviation detected (SERx of Bit #1
parameter No.8162 is set to 1), this parameter specifies the limit of the
difference between the positioning deviation of the slave axis and that
of the master axis. Set this parameter to the slave axis.
8183 Composite control axis of the other path in composite control for each axis
[Input type] Parameter input
[Data type] Word axis
[Valid data range] 101, 102, 103, . . . , (path number)*100+(intra-path relative axis
number) (101, 102, 103, . . . , 201, 202, 203, . . . , 1001, 1002,
1003, . . .)
This parameter sets with which axis each axis is to be placed under
composite control. When zero is specified, control of the axis is not
replaced under composite control. An identical number can be
specified in two or more parameters, but composite control cannot be
exercised for all of tem at a time.
NOTE
When using the two-path interface, set this
parameter for path 2.
