30i/300i/300is-Model A, 31i/310i/310is-Model A and A5, Parameter manual Page 421

Parameter manual
B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 409 -
4.54 PARAMETERS OF FEED AXIS SYNCHRONOUS
CONTROL
#7 #6 #5 #4 #3 #2 #1 #0
8301 SYA
[Input type] Parameter input
[Data type] Bit path
# 4 SYA In the servo-off state in feed axis synchronous control, the limit of the
difference between the positioning deviation of the master axis and
that of the slave axis is:
0: Not checked.
1: Checked.
#7 #6 #5 #4 #3 #2 #1 #0
8302 SMA
[Input type] Parameter input
[Data type] Bit path
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 7 SMA When an absolute position detector is attached, and bit 4 (APZ) of
parameter No. 1815 for an axis in synchronous operation is set to OFF,
APZ of the pairing axis in synchronous operation is:
0: Not set to OFF.
1: Set to OFF.
#7 #6 #5 #4 #3 #2 #1 #0
8303 SOF SAF ATS ATE
[Input type] Parameter input
[Data type] Bit axis
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 0 ATE In feed axis synchronous control, automatic setting for grid
positioning is:
0: Disabled
1: Enabled
Set this parameter with a slave axis.
Previous page
Next page
