Parameter manual
B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 417 -
8336 Synchronization error compensation gain 2 for each axis
[Input type] Parameter input
[Data type] Word axis
[Valid data range] 0 to 1024
This parameter sets synchronization error compensation gain 2 for
synchronization error smooth suppression.
Set this parameter with a slave axis.
NOTE
Set a value less than the value set in parameter
No. 8334.
8337 M code for turning off synchronization in feed axis synchronous control
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 1 to 999999999
This parameter specifies an M code for switching from synchronous
operation to normal operation.
The M code set in this parameter is not buffered.
8338 M code for turning on synchronization in feed axis synchronous control
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 1 to 999999999
This parameter specifies an M code for switching from normal
operation to synchronous operation.
The M code set in this parameter is not buffered.
