4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 426 -
4.58 PARAMETERS OF HIGH-SPEED POSITION SWITCH (1 OF
2)
#7 #6 #5 #4 #3 #2 #1 #0
8500 HPE
[Input type] Parameter input
[Data type] Bit path
# 7 HPE The maximum number of high-speed position switches is:
0: 6.
1: 16.
#7 #6 #5 #4 #3 #2 #1 #0
8501 HPD HPS HPF
[Input type] Parameter input
[Data type] Bit path
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 0 HPF The output signal of a high-speed position switch is output to:
0: Address Y.
1: Address F.
# 1 HPS The current position used with the high-speed position switch:
0: Considers a servo error.
1: Does not consider a servo error.
# 2 HPD When a high-speed position switch of direction decision type has
reached (not passed) a set coordinate in a specified direction, the
switch:
0: Does not operate.
1: Operates.
