4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 448 -
10806
Compensation point number of the reference position for three-dimensional
error compensation (first compensation axis)
10807
Compensation point number of the reference position for three-dimensional
error compensation (second compensation axis)
10808
Compensation point number of the reference position for three-dimensional
error compensation (third compensation axis)
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 1 to number of compensation points
These parameters set the compensation point number of the reference
position for each axis for three-dimensional error compensation.
10809
Magnification for three-dimensional error compensation (first compensation
axis)
10810
Magnification for three-dimensional error compensation (second
compensation axis)
10811
Magnification for three-dimensional error compensation (third compensation
axis)
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 1 to 100
These parameters set the magnification for each axis for
three-dimensional error compensation.
