30i/300i/300is-Model A, 31i/310i/310is-Model A and A5, Parameter manual Page 475

Parameter manual
B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 463 -
12313
States of the first manual handle feed axis selection signals when the first
rotation axis is turned in tool tip center rotation handle feed/interrupt
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 1 to 24
This parameter sets the states of the first manual handle feed axis
selection signals (HS1A to HS1E)/manual handle interrupt axis
selection signals (HS1IA to HS1IE) when the first rotation axis is
turned in tool tip center rotation handle feed/interrupt. (For a value to
be set, see "Table of correspondence with the manual handle feed axis
selection signals" provided in the description of parameter No.
12310.)
12314
States of the first manual handle feed axis selection signals when the
second rotation axis is turned in tool tip center rotation handle feed/interrupt
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 1 to 24
This parameter sets the states of the first manual handle feed axis
selection signals (HS1A to HS1E)/manual handle interrupt axis
selection signals (HS1IA to HS1IE) when the second rotation axis is
turned in tool tip center rotation handle feed/interrupt. (For a value to
be set, see "Table of correspondence with the manual handle feed axis
selection signals" provided in the description of parameter No.
12310.)
12318 Tool length in 5-axis machining manual feed
[Input type] Setting input
[Data type] Real path
[Unit of data] mm, inch (machine unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 to +999999.999)
This parameter sets a tool length when tool tip center rotation feed is
performed with the 5-axis machining manual feed function and when
the 5-axis machining manual feed screen is displayed.
NOTE
Specify a radius value to set this parameter.
