B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 491 -
13252 M code for specifying a particular tool
[Input type] Parameter input
[Data type] Word path
[Valid data range] 0 to 65535
This parameter sets not a tool type number but an M code for directly
specifying the T code of a particular tool.
13260 Customization data number to be searched for
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 0 to 40
When bit 6 (SWC) of parameter No. 13203 is set to 1, this parameter
sets a customization data number to be searched for.
The valid data range is 1 to 4 when the option for customization data
extension is not selected. When the option for customization data
extension (5 to 20) is selected, the valid data range is 1 to 20. When
the option for customization data extension (5 to 40) is selected, the
valid data range is 1 to 40.
When bit 6 (SWC) of parameter No. 13203 is set to 0, or a value not
within the valid data range is set, the search function based on
customization data is disabled, and the tool with the shortest lifetime
is searched for.
13265 Number for selecting a spindle position offset number
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 0 to 999
This parameters sets an H/D code for selecting an offset number
registered in the data of the tool attached at the spindle position.
When 0 is set, an ordinary used code such as H99/D99 is used.
When a value other than 0 is set, H99/D99 no longer has a particular
meaning. So, when H99/D99 is specified in this case, the specification
of offset number 99 is assumed.
With the T series, address D only is used to specify a tool number and
offset number, so that a restriction is imposed on the number of digits.
So, the valid data range of this parameter varies according the number
of digits of an offset number.
When the number of digits of an offset number is 1: to 9
When the number of digits of an offset number is 2: to 99
When the number of digits of an offset number is 3: to 999
