4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 492 -
4.70 PARAMETERS OF THE MACHINING CONDITION
SELECTION FUNCTION
#7 #6 #5 #4 #3 #2 #1 #0
13600 MCR
[Input type] Parameter input
[Data type] Bit path
# 0 MCR When an allowable acceleration rate adjustment is made with the
machining condition selection function (machining parameter
adjustment screen, precision level selection screen), parameter No.
1735 for the deceleration function based on acceleration in circular
interpolation is:
0: Modified.
1: Not modified.
#7 #6 #5 #4 #3 #2 #1 #0
13601 MPR
[Input type] Parameter input
[Data type] Bit
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 0 MPR The machining parameter adjustment screen is:
0: Displayed.
1: Not displayed.
Even when this parameter is set to 1, the precision level selection
screen is displayed.
