B-63950EN/02 4.DESCRIPTION OF PARAMETERS

- 495 -

NOTE

1 For an axis with 0 set in this parameter, parameter

No. 13614 and No. 13615 (allowable acceleration

rate change amount in speed control based on

acceleration rate change under control on the rate

of change of acceleration) are valid.

2 For an axis with 0 set in parameter No. 13614 and

No. 13615 (allowable acceleration rate change

amount in speed control based on acceleration rate

change under control on the rate of change of

acceleration), speed control based on acceleration

rate change is disabled, so that the specification of

this parameter has no effect.

13618

Rate of change time of the rate of change of acceleration in smooth

bell-shaped acceleration/deceleration before interpolation when AI contour

control is used (precision level 1)

13619

Rate of change time of the rate of change of acceleration in smooth

bell-shaped acceleration/deceleration before interpolation when AI contour

control is used (precision level 10)

[Input type] Parameter input

[Data type] Byte path

[Unit of data] %

[Valid data range] 0 to 50

Each of these parameters sets the rate (percentage) of the change time

of the rate of change of acceleration to the change time of acceleration

rate change in smooth bell-shaped acceleration/deceleration before

look-ahead interpolation during AI contour control.

Set a value (precision level 1) with emphasis placed on speed, and a

value (precision level 10) with emphasis on precision.

NOTE

When 0 or a value not within the valid data range is

set in this parameter, smooth bell-shaped

acceleration/deceleration before look-ahead

interpolation is not performed.
