4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 516 -
19535
Limit of travel distance moved with the cylindrical interpolation cutting point
compensation in the previous block unchanged.
[Input type] Parameter input
[Data type] Real path
[Unit of data] mm, inch (input unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 1 to 999999999
The following operation is performed, depending on the type of
interpolation:
1) For linear interpolation
If the travel distance in a specified block is smaller than the value
set in this parameter, machining is performed without changing
the cylindrical interpolation cutting point compensation in the
previous block.
2) For circular interpolation
If the diameter of a specified arc is smaller than the value set in
this parameter, machining is performed without changing the
cylindrical interpolation cutting point compensation in the
previous block. Cylindrical interpolation cutting point
compensation is not performed according to a circular
movement.
