1. Fanuc
  2. 30i/300i/300is-Model A, 31i/310i/310is-Model A and A5,

30i/300i/300is-Model A, 31i/310i/310is-Model A and A5, Parameter manual Page 63

Parameter manual
B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 51 -
4.9 PARAMETERS OF COORDINATES
#7 #6 #5 #4 #3 #2 #1 #0
WZR NWS FPC ZCL ZPR
1201
WZR FPC ZCL ZPR
[Input type] Parameter input
[Data type] Bit path
# 0 ZPR Automatic setting of a coordinate system when the manual reference
position return is performed
0: Not set automatically
1: Set automatically
NOTE
ZPR is valid while a workpiece coordinate system
function is not provided. If a workpiece coordinate
system function is provided, making a manual
reference position return always causes the
workpiece coordinate system to be established on
the basis of the workpiece zero point offset
(parameters No. 1220 to No. 1226), irrespective of
this parameter setting.
# 2 ZCL Local coordinate system when the manual reference position return is
performed
0: The local coordinate system is not canceled.
1: The local coordinate system is canceled.
NOTE
ZCL is valid when the workpiece coordinate system
option is specified. In order to use the local
coordinate system (G52), the workpiece coordinate
system option is required.
# 3 FPC When a floating reference position is set with a soft key, the relative
position indication is:
0: Not preset to 0 (The relative position indication remains
unchanged.)
1: Preset to 0.
# 6 NWS The workpiece coordinate system shift amount setting screen is:
0: Displayed
1: Not displayed
