2.3 References

2.3.1 User references

This section explains the references which can be used in a PMC program.

The following lists the valid range of PMC addresses.

Name Range Size Attribute Remarks

Corresponding

PMC-SB7 references

%I 1- 1024

10001 - 11024

80001 - 81024

1-bit (BOOL type) Read-only Input from I/O Link 1st channel

Input from I/O Link 2nd channel

Input from built-in I/O

X0.0 - X127.7

X200.0 - X327.7

X1000.0 - X1127.7

%IF 1- 6144

10001 - 16144

20001 - 26144

30001 - 36144

1-bit (BOOL type) Read-only Input from CNC *3

F0.0 - F767.7

F1000.0 - F1767.7

F2000.0 - F2767.7

F3000.0 - F3767.7

%Q 1- 1024

10001 - 11024

80001 - 81024

1-bit (BOOL type) Output to I/O Link 1st channel

Output to I/O Link 2nd channel

Output to built-in I/O

Y0.0 - Y127.7

Y200.0 - Y327.7

Y1000.0 - Y1127.7

%QG 1- 6144

10001 - 16144

20001 - 26144

30001 - 36144

1-bit (BOOL type) Output to CNC *3

G0.0 - G767.7

G1000.0 - G1767.7

G2000.0 - G2767.7

G3000.0 - G3767.7

%R 1- 5000 16-bit (WORD type) Retentive Data Register D0.0 - D9999.7

%M 1- 64000 1-bit (BOOL type) Internal relay R0.0 - R7999.7

%ME 1- 64000 1-bit (BOOL type) *7 E0.0 - E7999.7

%MA 1- 2000 1-bit (BOOL type) Message display request A0.0 - A249.7

%MK 1- 800 1-bit (BOOL type) Retentive Internal relay K0.0 - K99.7

%S 1- 3872 1-bit (BOOL type) Read-only System area *6 R9016.0 - R9499.7

%ST 1- 64 1-bit (BOOL type) Read-only *6 R9008.0 - R9015.7

%SA 1- 2000 1-bit (BOOL type) Read-only *8 A9000.0 - A9249.7

%SK 1- 160 1-bit (BOOL type) Retentive *9 K900.0 - K919.7
