FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

194/

316

TITLE

DRAW.NO.

4.7 IL Data Table Functions

Data Table Functions

Use these IL functions to copy a specified number of data elements from a source array to a destination array.

§ Array Move

§ Search for values in a Memory Block

4.7.1 Array Move

4.7.1.1 ARRAY_MOVE_INT( sr, snx, dnx, n, length, ds)

When the function receives power flow, the number of data elements in the count indicator 'n' is extracted from the

input array starting with the indexed location ('sr' + 'snx' – 1). The data elements are written to the output array starting

with the indexed location ('ds' + 'dnx' – 1).

sr: INT variable; the first element of the source array.

snx: UINT, variable or constant; the index into the source array.

dnx: UINT, variable or constant; the index into the destination array.

n: UINT, variable or constant; count indicator.

ds: INT variable; the first element of the destination array.

length: Constant; the number (1 - 32767) of elements (starting at 'sr' and 'ds') that make up each array.

4.7.1.2 ARRAY_MOVE_UINT( sr, snx, dnx, n, length, ds)

When the function receives power flow, the number of data elements in the count indicator 'n' is extracted from the

input array starting with the indexed location ('sr' + 'snx' – 1). The data elements are written to the output array starting

with the indexed location ('ds' + 'dnx' – 1).

sr: UINT variable; the first element of the source array.

snx: UINT, variable or constant; the index into the source array.

dnx: UINT, variable or constant; the index into the destination array.

n: UINT, variable or constant; count indicator.

ds: UINT variable; the first element of the destination array.

length: Constant; the number (1 - 32767) of elements (starting at 'sr' and 'ds') that make up each array.

4.7.1.3 ARRAY_MOVE_DINT( sr, snx, dnx, n, length, ds)

When the function receives power flow, the number of data elements in the count indicator 'n' is extracted from the

input array starting with the indexed location ('sr' + 'snx' – 1). The data elements are written to the output array starting

with the indexed location ('ds' + 'dnx' – 1).
