FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

24/

316

TITLE

DRAW.NO.

an alarm message or 255 (255 bytes) for an operator message.

An alphanumeric character requires 1 byte. For other special characters

including half-size kana characters and kanji characters (full-size

characters), note the following: a half-size kana character requires 2 bytes, a

kanji character requires 4 bytes, and character "@" used to code a special

character requires 1 byte.

Message Number

Always specify a message number for each message data item.

The relationships between message numbers and their display are shown

below:

Message

numbers

Destination CNC

screen

Display

1000 to 1999 Alarm screen

(on path 1)

Alarm messages

- Path 1 is placed in the alarm state.

2000 to 2099 Operator messages

2100 to 2999

Operator

message screen

Operator messages (with no message

numbers)

- Only message data is displayed, and no

message number is displayed.

5000 to 5999 Alarm screen

(on path 2)

Alarm message

- Path 2 is placed in the alarm state.

- The displayed message number is a

specified number from which 4000 is

subtracted.

7000 to 7999 Alarm screen

(on path 3)

Alarm message

- Path 3 is placed in the alarm state.

- The displayed message number is a

specified number from which 6000 is

subtracted.

NOTE

If a message number other than the above is specified, no message is

displayed.

Path Number

Always specify a path number for each message data item.

Each message is displayed on the screen for the path indicated by the
