5.4.4.3.1 PROGRAMMER ENABLE (%SK2)

If you set ”PROGRAMMER ENABLE ” to ”YES”, it enables the following

functions as a supervisor mode.

- Start/stop of ladder

- Forcing function

- Override function *1

- I/O screen

- Online setting screen

- Setting screen for keep relay %SK

5.4.4.3.2 HIDE PMC PROGRAM (%SK1)

If you set ”HIDE PMC PROGRAM” to ”YES”, it disables the following

functions which have the sequence program display.

- Writing of sequence program on the I/O screen

NOTE

1 The override function also requires the setting of ”OVERRIDE

ENABLE” in the setting parameters.

CAUTION

Set this setting to ”NO”(0) before shipment of the machine.

If this setting

is left as ”YES”(1), the operator may stop execution of the ladder program

by mistake. If you want to protect this setting, please make a sequence that

always writes 0 in this bit by your ladder.

NOTE

Even if this parameter is set to "YES", these settings are invalid if

"PROGRAMMER ENABLE" is set to "YES".
