Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 314

Additional Manual

Page of 317

/ 317

FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

313/

316

TITLE

DRAW.NO.

ER12 OPTION AREA

ERROR(xxxx)

Contact FANUC to reconfigure the

PMC management software.

The PMC management software is invalid.

(The series of BASIC and OPTION do not

match.)

ER13 OPTION AREA

ERROR(xxxx)

Contact FANUC to reconfigure the

PMC management software.

The PMC C board management software is

invalid.

(The series of BASIC and OPTION do not

match.)

ER14 OPTION AREA VERSION

ERROR (xxxx)

Contact FANUC to reconfigure the

PMC management software.

The PMC management software is invalid.

(The editions of BASIC and OPTION do not

match.)

ER15 OPTION AREA VERSION

ERROR (xxxx)

Contact FANUC to reconfigure the

PMC management software.

The PMC C board management software is

invalid.

(The editions of BASIC and OPTION do not

match.)

ER16 RAM CHECK ERROR

(PROGRAM RAM)

Replace the master printed circuit

board.

The initialization of the memory used to

store the sequence program failed.

ER17 PROGRAM PARITY 1) Re-input the sequence program.

2) Replace the master printed

circuit board.

The parity of the sequence program is

invalid.

ER18 PROGRAM DATA ERROR

BY I/O

Re-input the sequence program. While the sequence program was being

read, an interrupt command was generated.

ER22 PROGRAM NOTHING 1) Re-input the sequence program.

2) Replace the master printed

circuit board.

The sequence program is empty.

ER23 PLEASE TURN OFF

POWER

Turn the CNC off and then back on. With a change in the PMC type, for

example, the power must be turned off and

then back on.

ER25 SOFTWARE VERSION

ERROR (PMCAOPT)

Contact FANUC to reconfigure the

PMC management software.

The PMC management software is invalid.

(The edition of PMCAOPT does not match.)

ER26 PMC CONTROL MODULE

ERROR(PMCAOPT)

1) Contact FANUC to reconfigure

the PMC management software.

2) 2) Replace the master printed

circuit board.

The initialization of the PMC management

software failed.

ER32 NO I/O DEVICE 1) Check that the I/O device is on.

2) Check that the I/O device was

turned on before the CNC was

turned on.

3) Check the connection of the

cable.

An I/O device such as the I/O Link,

connection unit, and Power Mate is not

connected.

ER33 I/O LINK ERROR Replace the master printed circuit

board.

The LSI of the I/O Link is defective.

ER34 I/O LINK ERROR (xx) 1) Check the connection of the

cable leading to a device in

group xx.

2) Check that the I/O device was

turned on before the CNC.

3) Replace that device in group xx

in which the PMC control module

is installed.

In a slave in group xx, an error occurred in

communication with an I/O device.
