Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 315

Additional Manual

Page of 317

/ 317

FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

314/

316

TITLE

DRAW.NO.

ER35 TOO MUCH OUTPUT DATA

IN GROUP (xx)

Reduce the amount of output data in

group xx.

The amount of output data in I/O Link group

xx exceeds the limit (33 bytes). The excess

data is nullified.

ER36 TOO MUCH INPUT DATA IN

GROUP (xx)

Reduce the amount of input data in

group xx.

The amount of input data in I/O Link group

xx exceeds the limit (33 bytes). The excess

data is nullified.

ER38 MAX SETTING OUTPUT

DATA OVER (xx)

Modify the total amount of output

data in each group to 128 bytes or

less.

The I/O Link I/O area is insufficient.

(The allocation of any group after group xx

on the output side is nullified.)

ER39 MAX SETTING INPUT DATA

OVER (xx)

Modify the total amount of input data

in each group to 128 bytes or less.

The I/O Link I/O area is insufficient.

(The allocation of any group after group xx

on the input side is nullified.)

ER40 I/O LINK-II SETTING

ERROR (CHx)

Reconfigure the I/O Link-II. The I/O Link-II setting is invalid.

(CH1: Primary board, CH2: Secondary

board)

ER41 I/O LINK-II MODE

ERROR(CHx)

Reconfigure the I/O Link-II. The I/O Link-II mode setting is invalid.

(CH1: Primary board, CH2: Secondary

board)

ER42 I/O LINK-II STATION

NO.ERROR (CHx)

Reconfigure the I/O Link-II. The I/O Link-II station number setting is

invalid.

(CH1: Primary board, CH2: Secondary

board)

ER97 I/O LINK FAILURE

(CHx yyGROUP)

1) Check whether the cables of I/O

devices in group yy are connected

properly.

2) Check the power to each I/O

device.

3) Check the parameter setting of

the I/O link assignment data

selection function.

The number of assigned I/O modules in

group yy differs from that of I/O devices

actually connected.

WN02 OPERATE ADDRESS

ERROR

Modify the setting of the PMC

system parameter, address of the

operator’s panel for Series 0.

The setting of the PMC system parameter,

address of the operator’s panel for Series 0,

is invalid.

WN03 ABORT NC-WINDOW/EXIN 1) Check that the Ladder program

is free from problems and then

restart the Ladder program (by

pressing the RUN key).

2) Turn the CNC off and then back

on.

The Ladder program was stopped during

communication between the CNC and PMC.

Function instructions such as WINDR,

WINDW, EXIN, and DISPB may not be

executed normally.

WN05 PMC TYPE NO

CONVERSION

Using an offline programmer,

change the sequence program to

that for the correct PMC type.

The setting of the type in the sequence

program differs from the actual type.

(Example: For the PMC-SB5, the Ladder

program of the PMC-SA3/SA5 was

transferred.)

WN06 TASK STOPPED BY

DEBUG FUNC

To restart a user task that has been

stopped, stop the sequence program

and then execute it again.

When a PMC C board is used, a user task

has been stopped due to a break by a

debug function.

WN07 LADDER SP ERROR

(STACK)

Modify the sequence program so

that the subprogram nesting level is

eight or less.

For a subprogram call with the function

instruction CALL or CALLU, the nesting level

is too deep (exceeds 8).
