Parameters

Parameter Data type Meaning

EN BOOL Execution of operation

ADRS one-dimensional WORD array

of 3 words

ADRS is the beginning address

of a three-word WORD array:

Word 1: current step number

Word 2: length of sequence in

bits

Word 3: control word, which

tracks the status of the last

enabling power flow and the

status of the power flow to the

right.

LEN Constant

The length. The number of bits

in the bit sequencer, ST, that

BITSEQ will Step Through.

1<=LEN<=256

R BOOL Reset

DIR BOOL Direction of the bit sequencer

N INT Step number

ST BYTE The first byte of the bit

sequencer

ENO BOOL Returns the value of EN

Memory Type

Memory

Flow %I* %Q* %M* %S* %R

Constant

Omissible

EN o o o o o

R o o o o o

DIR o o o o o

N o o o o o o

ST o o o o o o

ENO o o o Note o o

Note Only %SK can be specified.

Example

The Bit Sequencer operates on register memory %R00001. Its static

data is stored in registers %R00010, %R00011, and %R00012. When

%I00002 is active, the sequencer is reset and the current step is set to

step number 3, as specified in N. The third bit of %R00001 is set to one
