Increment System 1/100 Additional Manual Page 1

Additional Manual
TECHNICAL REPORT (MANUAL)
No. TMN01/015
Date : Jan. 26, 2001
General Manager of
Software Laboratory
FANUC Series 16i/18i-TA
Increment System 1/100
1. Communicate this report to:
Your information only
○
GE Fanuc-N, GE Fanuc-E
FANUC Robotics
MILACRON
○
Machine tool builder
Sales agency
End user
2. Summary for Sales Documents
3. Notice
4. Attached Document
Drawing No.
A-78347E (1/6
6/6)
Copy :
SE, FLB1→FLB2
Original section of issue
Vice-General
Manager
Department
Manager
Section
Manager
Person in
Charge
IDE
No. FLB2-01/1166
Date Jan. 26, 2001
Previous page
Next page

Contents Summary of Increment System 1/100 Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) No. TMN01/015 Date : Jan. 26, 2001 General Manager of Software Laboratory FANUC Series 16i/18i-TA Increment System 1/100 1. Communicate this report to: Your information only ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON ○ Machine tool builder Sales agency End user 2. Sum
  • Page 2FANUC Series 16i/18i-TA Increment System 1/100 DS0100-04 FANUC Series 16i/18i-TA TITLE Increment System 1/100 01 00.09.18 Newly Registered No. A-78347E EDT. DATE DESIGN DESCRIPTION PAGE /
  • Page 3! Outline In the Increment System 1/100 (IS-D), the increment system is one hundredth of the standard increment system (IS-B). Ex.) mm input ------------- 0.00001[mm] inch input ------------ 0.000001[inch] ! Program command In case of using IS-D, the maximum command is eight digits as usual. The max
  • Page 4mm input / mm output Increment system IS-B IS-C IS-D Least input increment [mm] 0.001 0.0001 0.00001 Least command increment (Diameter) [mm] 0.0005 0.00005 0.000005 Least command increment (Radius) [mm] 0.001 0.0001 0.00001 Max. programmable dimension [mm] +-99,999.999 +-9,999.9999 +-999.99999 Max.
  • Page 5inch input / mm output Increment system IS-B IS-C IS-D Least input increment [inch] 0.0001 0.00001 0.000001 Least command increment (Diameter) [mm] 0.0005 0.00005 0.000005 Least command increment (Radius) [mm] 0.001 0.0001 0.00001 Max. programmable dimension [inch] +-3,937.0078 +-393.70078 +-39.3700
  • Page 6mm input / inch output Increment system IS-B IS-C IS-D Least input increment [mm] 0.001 0.0001 0.000001 Least command increment (Diameter) [inch] 0.00005 0.000005 0.0000005 Least command increment (Radius) [inch] 0.0001 0.00001 0.000001 Max. programmable dimension [mm] +-99,999.999 +-9,999.9999 +-99
  • Page 7inch input / inch output Increment system IS-B IS-C IS-D Least input increment [inch] 0.0001 0.00001 0.000001 Least command increment (Diameter) [inch] 0.00005 0.000005 0.0000005 Least command increment (Radius) [inch] 0.0001 0.00001 0.000001 Max. programmable dimension [inch] +-9,999.9999 +-999.999
