Page 1FANUC Series 16i /18i /21i -TB FANUC Series 16i /18i /21i -MB Cs-axis Coordinate Establishment Function (Note) This specification may be modified for improvement without notice. FANUC Series16i/18i/21i Title Cs-axis Coordinate Establishment Function Draw No. A-78845EN 02 Sep.30.’03 Modification at (
Page 2General Generally, position is lost just after changing serial spindle mode from speed control mode to Cs contour control mode. This function makes it possible to establish position without reference point return by setting Cs axis coordinate establishment request signal CSFIx to 1. Note
Page 3In case of failure to establish Cs axis coordinate When Cs axis coordinate establishment is failed, P/S alarm 5346 occurs on the path that counts up absolute coordinate (work coordinate). And, Cs axis coordinate establishment alarm signal CSFOx is set to 1 on the path connected with spind
Page 4Sequence(Time Chart) In case that Cs axis coordinate establishment is completed correctly. M code for Cs contour M code control MF CSPENA CSFIx CON or CONSx FSCSL or FCSSx Count up coordinate ZRFx CSFOx
Page 5In cast that Cs axis coordinate establishment is failed.( aborted by emergency stop, etc. ) M code for Cs contour M code control MF CSPENA CSFIx CON or CONSx FSCSL or FCSSx Abort Count up coordinate ZRFx CSFOx
Page 6Example) Under composite control of Cs axis in two-path system M code for Cs contor M code control MF CSPENA CSFIx CON FSCSL Count up coordinate ZRFx CSFOx FIN (1) Excute M code on path-1. Then, MF signal
Page 7Parameter #7 #6 #5 #4 #3 #2 #1 #0 1005 ZRN [Data type] Bit axis ZRNx When a command specifying the movement except for G28 is issued in automatic operation (MEM, RMT, or MDI) and when a return to the reference position has not been performed since the power was turned on 0: An alarm is generated (P/
Page 8#7 #6 #5 #4 #3 #2 #1 #0 (2) 4353 CSPTRE [Data type] Bit axis CSPTRE The function that transfer position data of Cs axis is 0: Not used 1: Used Set parameter RFCHK3(No.4016#7) to 0 in order to use this function. #7 #6 #5 #4 #3 #2 #1 #0 8161 CZM [Data type] Bit CZM When two Cs contour axes are subject
Page 9Cs axis coordinate establishment alarm signals CSFO1 ∼ CSFO4 [Classification] Output signal [Function] Inform that Cs axis coordinate establishment has not been completed. [Output condition] These signals are set to 1 in the following case: - Cs axis coordinate establishment has not been
Page 11Note CMR Set the same value of CMR( parameter No.1820) for all Cs axes to establish their coordinate in composite control. If value of CMR are different, coordinate establishment is not completed correctly. In case that CMR is larger than 1 (parameter No.1820>2), Cs axis might move for a little duri
Page 12Synchronous control If Cs axis coordinate establishment request signal CSFIx is set to 1 during synchronous control, P/S alarm 5346 occurs. Start synchronous control after Cs axis coordinate is established. Composite control(T only) Set parameter CZM(No.8161#1) to 1 in order to use Cs ax
Page 13Apply software, hardware The following software are needed in order to use Cs axis coordinate establishment function. NC system software Series-Edition FS16i/160i/160is-TB B1HA-06 or later FS18i/180i/180is-TB BEHA-06 or later FS21i/210i/210is-TB DEHA-06 or later FS16i/160i/160is-MB B0HA-04 or later
Page 14Reference item FANUC AC SPINDLE MOTOR αi series 2.4 Cs Contour Control PARAMETER MANUAL (B–65280EN) FANUC Series 9.9 Cs Contour Control 16i/160i/160is/18i/180i/180is/21i/210i/2 10is-MODEL B CONNECTION MANUAL (FUNCTION) (B-63523EN-1) Cs contour control by each serial spindle SPECIFICATION (A-61154E)
