8.2.6
Spindle Parameter(No.4000
∼
∼∼
∼
4799, No.3701etc.)
You set the spindle parameter automatically.
Procedure
1.
You set DI signal G193#0(DTM) to “0” in order to display the
screen of the turning side (T-DSP) display.
2.
You set the spindle parameter automatically. Please refer to the
document for the spindle amplifier for details.
3.
After completing automatic parameter setting, you push software
keys as follows on the parameter screen in order to output
parameters to the i/o device.
[(OPER.)] -> [PUNCH] -> [ALL] -> [EXEC.]
4.
You input the parameter output to CNC a little while ago. This
operation influences the parameter for the milling mode (M-
MOD).
5.
If necessary, you change the spindle parameter.
NOTICE
The spindle parameter must be set on both the turning display (T-
DSP) and the turning mode (T-MOD).
Mode Parameter setting method Operation
T-MOD MDI input and input from I/O
device on M-DSP
The setting does not influence
the movement of the motor.
T-MOD MDI input and input from I/O
device on T-DSP
Normal completion
T-MOD Setting to path 1 with CNC
Window
Normal completion
M-MOD MDI input and input from I/O
device on M-DSP
Normal completion
M-MOD MDI input and input from I/O
device on T-DSP
The setting does not influence
the movement of the motor.
M-MOD Setting to path 1 with CNC
Window
The setting does not influence
the movement of the motor.
