FANUC Series16i /18i /21i –MA/TA
Embedded Macro
A-77900E
2000.04.11
6. Parameters
#7 #6 #5 #4 #3 #2 #1 #0
12001
IMREP
[ Data type ] Bit
IMREP Action in response to an attempt to register an embedded macro program whose
number is the same as that of an existing program
0: An alarm is generated.
1: The existing program is deleted, then the new program is registered. Note that
if the existing program is protected from being edited, it is not deleted, and an
alarm is generated.
REP
(Prm.No.3201#2)
IMREP
(Prm.No.12001#0)
Tape storage
memory program
Embedded macro
program
00AlarmAlarm
0 1 Alarm Registration
1 0 Registration Alarm
1 1 Registration Registration
(Note 1) When the CNC power supply is turned on or the <RELOAD> operation
is done, this parameter is rewritten by the embedded macro data in
FROM.
(Note 2) When the CNC is Lock State, the embedded macro data in FROM is
used.
