4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 128 -

depending on whether the slave is an amplifier or separate detector

interface unit, or when no slave exists.

• When the slave is an amplifier:

Set the value obtained by subtracting 1 from the setting of

parameter No.1023 for the axis to which the amplifier is

assigned.

• When the slave is a separate detector interface unit:

Set 16

for the first separate detector interface unit (closest to the

CNC).

Set 48

for the second separate detector interface unit (furthest

from the CNC).

• When no slave exists

Set 40

NOTE

When automatic setting mode is selected for FSSB

setting (when the FMD parameter (bit 0 of

parameter No.1902) is set to 0), parameters

No.1910 to No.1919 are automatically set when

input is performed with the FSSB setting screen.

When manual setting 2 mode is selected for FSSB

setting (when the FMD parameter (bit 0 of

parameter No.1902) is set to 1), parameter

No.1910 to No.1919 must be directly set.
