0i/0i Mate - Model C Parameter manual Page 148

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 136 -
No. Data type Contents
2319 Word axis Inertial ratio of disturbance filter
2320 Word axis Inverse function gain of disturbance filter
2321 Word axis Filter time constant of disturbance filter
2322 Word axis Acceleration feedback limit of disturbance filter
2323 Word axis Variable current PI ratio
2324 Word axis Proportional gain change function at stop Any magnification at stop (for cutting only)
2325 Word axis Tandem vibration-damping control/integral gain (main axis) Phase coefficient (sub-axis)
2326 Word axis Disturbance input gain
2327 Word axis Starting frequency of disturbance input
2328 Word axis Ending frequency of disturbance input
2329 Word axis Number of disturbance input measurement points
2333 Word axis Tandem vibration-damping control/incomplete integral time constant (main axis)
2334 Word axis Current loop gain magnification (valid only during high-speed HRV current control)
2335 Word axis Velocity loop gain magnification (valid only during high-speed HV current control)
2338 Word axis Stage 2 acceleration limit amount for two-stage backlash acceleration
2339 Word axis Stage 2 acceleration amount for two-stage backlash acceleration (negative direction)
2340 Word axis Stage 2 acceleration amount override for two-stage backlash acceleration (negative
direction)
2341 Word axis Stage 2 acceleration limit amount for two-stage backlash acceleration (negative direction)
2345 Word axis Dynamic friction compensation amount at stop in abnormal load detection
2346 Word axis Dynamic friction compensation limit in abnormal load detection
2352 Word axis Detection level of active vibration-damping filter
2359 Word axis Damping of vibration-damping filter 1
2360 Word axis Attenuation center frequency of vibration-damping filter 2
2361 Word axis Attenuation band width of vibration-damping filter 2
2362 Word axis Damping of vibration-damping filter 2
2363 Word axis Attenuation center frequency of vibration-damping filter 3
2364 Word axis Attenuation band width of vibration-damping filter 3
2365 Word axis Damping of vibration-damping filter 3
2366 Word axis Attenuation center frequency of vibration-damping filter 4
2367 Word axis Attenuation band width of vibration-damping filter 4
2368 Word axis Damping of vibration-damping filter 4
2369 Word axis Two smooth compensation operations per magnetic pole pair (negative direction)
2370 Word axis Four smooth compensation operations per magnetic pole pair (negative direction)
2371 Word axis Six smooth compensation operations per magnetic pole pair (negative direction)
2373 Word axis Pull-up amount of vertical axis pull-up function at emergency stop
2374 Word axis Pull-up time of vertical axis pull-up function at emergency stop
2395 Word axis Feed-forward timing adjustment function (when FAD is enabled)
