0i/0i Mate - Model C Parameter manual Page 162

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 150 -
0 : Spindle motor speed
1 : Spindle speed
NPA Action taken when an alarm is generated or when an operator message
is entered
0 : The display shifts to the alarm or message screen.
1 : The display does not shift to the alarm or message screen.
#7 #6 #5 #4 #3 #2 #1 #0
3112 OPH EAH OMH SGD
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Data type] Bit
SGD Servo waveform
0 : Not displayed
1 : Displayed
NOTE
If SGD is set to 1, no graphic display other than
servo waveform display is done.
OMH The external operator message history screen is:
0 : Not displayed.
1 : Displayed.
EAH Messages of the external alarm/macro alarm in alarm history:
0 : Not recorded
1 : Recorded
OPH The operation history log function is:
0 : Displayed.
1 : Enable.
#7 #6 #5 #4 #3 #2 #1 #0
3113 MS1 MS0 MHC
[Data type] Bit
MHC External operator message history data:
0 : Cannot be cleared.
1 : Can be cleared.
(Such data can be cleared using the [CLEAR] soft key.)
MS0, MS1 A combination of the number of characters preserved as external
operator message history data and the number of history data items is
set according to the table below.
MS1 MS0
Number of history data
characters
Number of history data
items
0 0 255 8
0 1 200 10
1 0 100 18
1 1 50 32
