0i/0i Mate - Model C Parameter manual Page 23

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 11 -
#7 #6 #5 #4 #3 #2 #1 #0
0002 SJZ RDG
Setting entry is acceptable.
[Data type] Bit
RDG Remote diagnosis is
0: Not performed.
1: Performed.
To use an RS-232-C serial port for performing remote diagnosis,
connect and setup the modem, cable, and the like, then set 1 in this
parameter. When using a modem card, the setting is not necessary.
SJZ Manual reference position is performed as follows:
0 : When no reference position has been set, reference position
return is performed using deceleration dogs. When a reference
position is already set, reference position return is performed
using rapid traverse and deceleration dogs are ignored.
1 : Reference position return is performed using deceleration dogs at
all times.
NOTE
SJZ is enabled when bit 3 (HJZ) of parameter
No.1005 is set to 1. When a reference position is
set without a dog, (i.e. when bit 1 (DLZ) of
parameter No.1002 is set to 1 or bit 1 (DLZx) of
parameter No.1005 is set to 1) reference position
return after reference position setting is performed
using rapid traverse at all times, regardless of the
setting of SJZ.
#7 #6 #5 #4 #3 #2 #1 #0
RMVx AICx MIRx
0012
RMVx MIRx
Setting entry is acceptable.
[Data type] Bit axis
MIRx Mirror image for each axis
0 : Mirror image is off.
1 : Mirror image is on.
AICx The travel distance of an axis command is:
0: Determined by the value specified with the address.
1: Always handled as an incremental value.
