B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 329 -

7066

Acceleration/deceleration reference speed for the bell-shaped

acceleration/deceleration time constant change function in AI contour

control mode

[Data type] 2 word

[Unit of data, valid data range]

Valid data range

Increment system Units of data

IS-B IS-C

Millimeter input 1 mm/min 0 - 600000 0 - 60000

Inch machine 0.1 inch/min 0 - 600000 0 - 60000

Set the acceleration/deceleration reference speed for the function for

changing the time constant of bell-shaped acceleration/deceleration

before interpolation (bit 3 (BCG) of parameter No. 7055 = 1) in AI

contour control.

Since this parameter is set in the input unit, when the input unit has

been changed, the setting of the parameter must be changed.
