0i/0i Mate - Model C Parameter manual Page 346

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 334 -
4.40 PARAMETERS OF BUTT-TYPE REFERENCE POSITION
SETTING
7181 First withdrawal distance in butt-type reference position setting
[Data type] 2-word axis
[Unit of data]
Input increment IS-A IS-B IS-C Unit
Millimeter input 0.01 0.001 0.0001 mm
Inch input 0.001 0.0001 0.00001 inch
[Valid data range] -99999999 to 99999999
When the butt-type reference position setting is used, this parameter
sets a distance an axis, along which withdrawal is performed after the
mechanical stopper is hit (distance from the mechanical stopper to the
withdrawal point).
NOTE
Set the same direction as that set in bit 5 (ZMIx) of
parameter No. 1006. Cycle operation cannot be
started if the opposite direction is set.
7182 Second withdrawal distance in butt-type reference position setting
[Data type] 2-word axis
[Unit of data]
Input increment IS-A IS-B IS-C Unit
Millimeter input 0.01 0.001 0.0001 mm
Inch input 0.001 0.0001 0.00001 inch
[Valid data range] -99999999 to 99999999
When the butt-type reference position setting is used, this parameter
sets a distance an axis, along which withdrawal is performed after the
mechanical stopper is hit (distance from the mechanical stopper to the
withdrawal point).
NOTE
Set the same direction as that set in bit 5 (ZMIx) of
parameter No. 1006. Cycle operation cannot be
started if the opposite direction is set.
